Kia Sephia II (1997-2001) flasher module Wiring diagram
This page shows the only wiring diagram for the component.flasher module, which is found in the car Kia Sephia II (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram flasher module (1 of 1)
ABS WARNING MODULE
BLK WIRE
BLOWER MOTOR RELAY
BLOWER SWITCH
BRAKE FLUID LEVEL SWITCH
CIGARETTE LIGHTER
CLUTCH PEDAL POSITION SWITCH
COMBINATION SWITCH
CONDENSOR FAN RELAY
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL UNIT
DIGITAL CLOCK
DOOR KNOB LOCK SWITCH
ELECTRONIC TIME CONTROL MODULE
ENGINE COMPARTMENT FUSE , RELAY BOX
ENGINE COMPT FUSE/RELAY BOX
FLASHER MODULE
FRESH/ RECIRCULATION SWITCH
FUEL PUMP
FUEL TANK UNIT
HEADLIGHT SWITCH
HEATER-A/C CONTROL PANEL
HIGH MOUNT STOP LIGHT
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMER SWITCH
J/C 3
J/C 4
J/C 5
J/C 6
JC-13
JC-20
LEFT LICENSE LIGHT
LEFT REAR LIGHT ASSEMBLY RIGHT REAR LIGHT ASSEMBLY
LEFT REAR POWER WINDOW SWITCH
MASTER POWER WINDOW SWITCH
NCA WIRE
O/D OFF SWITCH
POWER DOOR LOCK RELAY
POWER MIRROR CONTROLLER
RADIO
REAR WINDOW DEFROSTER SWITCH
RIGHT FRONT POWER WINDOW SWITCH
RIGHT LICENSE LIGHT
SAFETY BELT SWITCH
SHIFT LOCK ACTUATOR
VEHICLE SPEED SENSOR
WIPER/ WASHER SWITCH
Go to component -> Ground distribution circuit (2 of 2) -> FLASHER MODULE
