Kia Sephia II (1997-2001) brake switch input right fr whl sen input right fr whl sen input Wiring diagram
This page shows the only wiring diagram for the component.brake switch input right fr whl sen input right fr whl sen input, which is found in the car Kia Sephia II (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake switch input right fr whl sen input right fr whl sen input (1 of 1)
1 2 3 4 5 GROUND ABS WARNING OUTPUT BRK FLUID LEV SW INPUT B+ MIL CONTROL
ABS FUSE
ABS INDICATOR
ABS WARNING INPUT
ABS WARNING MODULE (BELOW LEFT SIDE OF DASH)
ANTI-LOCK BRAKE CONTROL UNIT (LEFT REAR OF ENGINE COMPARTMENT)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID RESERVOIR)
BRAKE PEDAL SWITCH (BELOW LEFT SIDE OF DASH)
BRAKE SWITCH INPUT RIGHT FR WHL SEN INPUT RIGHT FR WHL SEN INPUT
BRAKE WARNING INDICATOR
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
DATA LINK CONNECTOR (DLC) (LEFT SIDE OF ENGINE COMPT)
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
J/C 11
J/C 14
J/C 2
J/C 4
LEFT FRONT WHEEL SENSOR (AT LEFT FRONT WHEEL)
LEFT REAR WHEEL SENSOR (AT RIGHT REAR WHEEL)
LT GRN/BLK WIRE
LT GRN/RED WIRE
LT GRN/YEL WIRE
METER FUSE
NCA WIRE
PARKING BRAKE SWITCH (BELOW CENTER CONSOLE)
PASSENGER COMPARTMENT FUSE BOX (BELOW LEFT SIDE OF DASH)
PNK WIRE
RED WIRE
RED/BLK WIRE
RIGHT FRONT WHEEL SENSOR (AT RIGHT FRONT WHEEL)
RIGHT REAR WHEEL SENSOR (AT RIGHT REAR WHEEL)
RIGHT REAR WHL SEN INPUT RIGHT REAR WHL SEN INPUT GROUND B+
STOP FUSE
VIO WIRE
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Anti-lock brake circuits -> BRAKE SWITCH INPUT RIGHT FR WHL SEN INPUT RIGHT FR WHL SEN INPUT
