Kia Sephia II (1997-2001) anti-lock brake control unit hazard switch Wiring diagram
This page shows the only wiring diagram for the component.anti-lock brake control unit hazard switch, which is found in the car Kia Sephia II (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram anti-lock brake control unit hazard switch (1 of 1)
A/C RELAY CONDENSER FAN RELAY
ANTI-LOCK BRAKE CONTROL UNIT HAZARD SWITCH
BATTERY
BLK WIRE
BLK/RED WIRE
BLOWER FUSE
BLOWER RELAY
BLU WIRE
CONDENSER FAN FUSE A/C FUSE
COOLING FAN FUSE
COOLING FAN RELAY
DATA LINK CONNECTOR (DLC)
DEFROSTER RELAY
DOOR LOCKS FUSE ABS FUSE BTN FUSE
EGI MAIN RELAY
ENGINE CONTROL MODULE
EVAP CANNISTER PURGE VALVE CAMSHAFT POSITION SENSOR
FRONT HEATED OXYGEN SENSOR
FUEL INJECTORS
FUEL PUMP
FUEL PUMP FUSE DOWN FUSE
FUEL PUMP RELAY
FUSE
GENERATOR
HAZARD FUSE ABS FUSE
HEAD FUSE FUSE
HEADLIGHT RELAY
HORN FUSE
HORN RELAY
IDLE AIR CONTROL VALVE CANISTER CLOSE
INJ FUSE
J/C 1
LIGHT SWITCH COMBINATION SWITCH
MASS AIRFLOW SENSOR
MASTER POWER WINDOW SWITCH
NCA WIRE
OBD II FUSE
OBD-II DATA LINK CONNECTOR
P/WIN LH FUSE P/WIN RH FUSE
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
POWER DOOR LOCK RELAY
POWER WINDOW RELAY
REAR HEATED OXYGEN SENSOR
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RR DEF FUSE
STARTER
TAIL LIGHT RELAY
TNS FUSE
TO ENGINE COMPARTMENT FUSE/RELAY BOX (DIAGRAM 3 OF 3)
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
TO PASSENGER COMPARTMENT FUSE BOX (DIAGRAM 2 OF 3)
UP FUSE
VALVE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> ANTI-LOCK BRAKE CONTROL UNIT HAZARD SWITCH
