Kia Sephia II (1997-2001) abs warning module Wiring diagrams
This page contains all the electrical diagrams for the component. abs warning module, in which he is found in the car Kia Sephia II (1997-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram abs warning module (1 of 2)
ABS WARNING MODULE
BLK WIRE
BLOWER MOTOR RELAY
BLOWER SWITCH
BRAKE FLUID LEVEL SWITCH
CIGARETTE LIGHTER
CLUTCH PEDAL POSITION SWITCH
COMBINATION SWITCH
CONDENSOR FAN RELAY
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL UNIT
DIGITAL CLOCK
DOOR KNOB LOCK SWITCH
ELECTRONIC TIME CONTROL MODULE
ENGINE COMPARTMENT FUSE , RELAY BOX
ENGINE COMPT FUSE/RELAY BOX
FLASHER MODULE
FRESH/ RECIRCULATION SWITCH
FUEL PUMP
FUEL TANK UNIT
HEADLIGHT SWITCH
HEATER-A/C CONTROL PANEL
HIGH MOUNT STOP LIGHT
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMER SWITCH
J/C 3
J/C 4
J/C 5
J/C 6
JC-13
JC-20
LEFT LICENSE LIGHT
LEFT REAR LIGHT ASSEMBLY RIGHT REAR LIGHT ASSEMBLY
LEFT REAR POWER WINDOW SWITCH
MASTER POWER WINDOW SWITCH
NCA WIRE
O/D OFF SWITCH
POWER DOOR LOCK RELAY
POWER MIRROR CONTROLLER
RADIO
REAR WINDOW DEFROSTER SWITCH
RIGHT FRONT POWER WINDOW SWITCH
RIGHT LICENSE LIGHT
SAFETY BELT SWITCH
SHIFT LOCK ACTUATOR
VEHICLE SPEED SENSOR
WIPER/ WASHER SWITCH
Go to component -> Ground distribution circuit (2 of 2) -> ABS WARNING MODULE
Wiring diagram abs warning module (2 of 2)
ABS WARNING MODULE
AIR BAG DIAGNOSTIC UNIT (BELOW CENTER OF DASH)
AIR BAG INDICATOR
ANTI-LOCK INDICATOR (ABS)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID RESERVOIR)
BRAKE WARNING IND. (BRAKE)
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CHARGE IND. (CHARGE)
CHARGING SYSTEM
CLUSTER ILLUM.
CRUISE CONTROL IND. (AUTO CRUISE)
CRUISE CONTROL UNIT (RIGHT REAR OF ENGINE COMPT)
DEFOGGER SYSTEM
DOOR AJAR IND. (DOOR)
ELECTRONIC TIME CONTROL MODULE (BELOW LEFT SIDE OF DASH)
ENGINE CONTROL MODULE
ENGINE COOLANT TEMPERATURE GAUGE
ENGINE COOLANT TEMPERATURE SENDER (ON LEFT REAR OF ENGINE)
FASTEN BELT IND. (BELTS)
FUEL GAUGE
FUEL TANK UNIT
FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND
GROUND (A/T) (M/T) 1 3 BATTERY (M/T) (A/T) 1 3 SPEED OUTPUT
HEADLIGHTS SYSTEM
HI-BEAM IND
HOLD
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION
IND
INPUT
INSTRUMENT CLUSTER
J/C 11
J/C 13 (OR
J/C 14
J/C 4
J/C 4 PARKING BRAKE SWITCH (BELOW CENTER CONSOLE)
LH TURN IND
LOW FUEL IND. (FUEL)
LOW OIL PRESSURE IND. (OIL)
LT GRN/RED WIRE
LT GRN/YEL WIRE
MALFUNC- TION IND. LAMP (CHECK)
METER FUSE
O/D OFF OR HOLD INDICATOR
OIL PRESSURE SWITCH (RIGHT SIDE OF ENGINE, NEAR OIL FILTER)
ORG/ WIRE
ORG/BLK (OR BRN/WHT) WIRE
ORG/BLK WIRE
PASSENGER COMPARTMENT ROOM FUSE FUSE BOX (BELOW LEFT SIDE OF DASH)
PNK WIRE
REAR DEFOGGER
RED WIRE
RED/BLK WIRE
RH TURN IND
SPEEDOMETER ASSEMBLY (SOLID STATE)
STARTING SYSTEM
TACHOMETER (SOLID STATE)
TRANSAXLE CONTROL MODULE (LEFT KICK PANEL)
VEHICLE SPEED OUTPUT
VEHICLE SPEED SENSOR (VSS) (LEFT SIDE OF ENGINE COMPT)
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Instrument cluster circuit -> ABS WARNING MODULE
