Instrument illumination circuit for Kia Sephia I facelift (1994-1998)
Instrument illumination circuit
A/C SWITCH
BLK WIRE
BLOWER SWITCH
CIGARETTE LIGHTER
CRUISE CONTROL MAIN SWITCH
DIGITAL CLOCK DIMMING INPUT
FRESH/ RECIR- CULATE SWITCH
GRN WIRE
GRY WIRE
HAZARD SWITCH
HEADLIGHTS SYSTEM TAIL FUSE
HEATER AND A/C CONTROL PANEL
HOT IN HEAD OR PARK
I/P DIMMER SWITCH
INSTRUMENT CLUSTER
J/C 4
LEFT REAR POWER WINDOW SWITCH
MASTER POWER WINDOW SWITCH
OSCILLATOR
PASSENGER COMPARTMENT FUSE BOX
PRNDL ILLUMINATION
RADIO
REAR WINDOW DEFROSTER SWITCH
RED WIRE
RIGHT FRONT POWER
RIGHT REAR POWER WINDOW SWITCH
W/ REMOVABLE FACEPLATE
W/O REMOVABLE FACEPLATE
WINDOW SWITCH
YEL WIRE
