Anti-theft circuit for Kia Sephia I facelift (1994-1998)
Anti-theft circuit
5 8 11 18 21 RADIO INPUT GND
ANTI-THEFT OUTPUT
BATTERY INPUT RADIO
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
ELECTRONIC TIME, ALARM CONTROL MODULE (LEFT SIDE OF I/P, ABOVE FUSE BOX)
FLASHER MODULE (BEHIND LEFT SIDE OF I/P, ON BRACKET ABOVE FUSE BOX)
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
HAZARD LIGHTS CONTROL
HAZARD SWITCH
HORN
HORN RELAY (BEHIND LEFT SIDE OF I/P, ON BRACKET ABOVE FUSE BOX)
HORN RELAY CTRL
HORNS SYSTEM (HORN SWITCH)
HOT AT ALL TIMES ROOM FUSE
HOT AT ALL TIMES STOP FUSE
HOT IN ON AND START
IGNITION INPUT
J/C 3 (BEHIND LEFT SIDE OF I/P, ABOVE FUSE BOX)
KEY IN IGNITION INPUT BAT INPUT
KEY-IN IGNITION SWITCH
METER FUSE
NCA WIRE
PASSENGER COMPARTMENT FUSE BOX
RED WIRE
SOLID STATE
W/ REMOVABLE FACEPLATE
W/O REMOVABLE FACEPLATE
