Kia Sephia I facelift (1994-1998) w/ removable faceplate w/o removable faceplate Wiring diagram
This page shows the only wiring diagram for the component.w/ removable faceplate w/o removable faceplate, which is found in the car Kia Sephia I facelift (1994-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ removable faceplate w/o removable faceplate (1 of 1)
BLK WIRE
BLOWER SWITCH
CIGARETTE LIGHTER
DIGITAL CLOCK
FRESH/ RECIRCULATION SWITCH
FUEL PUMP
FUEL TANK UNIT
HAZARD SWITCH
HEATER CONTROL PANEL
HIGH MOUNT STOP LIGHT
HOLD SWITCH
I/P DIMMER SWITCH
J/C 6 (BELOW LEFT SIDE OF I/P)
J/C 7 (RIGHT REAR OF TRUNK)
JAMB SWITCH
LEFT BACK-UP LIGHT
LEFT REAR LIGHT ASSEMBLY
LEFT REAR POWER WINDOW SWITCH
LICENSE LIGHT
O/D OFF SWITCH
OBD-II DATA LINK CONNECTOR
POWER MIRROR SWITCH
POWERTRAIN CONTROL MODULE (1997)
PRNDL ILLUMI- NATION
RADIO
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER SWITCH
RIGHT BACK-UP LIGHT
RIGHT REAR DOOR
RIGHT REAR LIGHT ASSEMBLY
RIGHT REAR POWER WINDOW SWITCH
TO J/C 4
TRUNK LIGHT SWITCH
W/ REMOVABLE FACEPLATE W/O REMOVABLE FACEPLATE
Go to component -> Ground distribution circuit (3 of 3) -> W/ REMOVABLE FACEPLATE W/O REMOVABLE FACEPLATE
