Kia Sephia I facelift (1994-1998) transaxle range switch cruise control unit Wiring diagram
This page shows the only wiring diagram for the component.transaxle range switch cruise control unit, which is found in the car Kia Sephia I facelift (1994-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transaxle range switch cruise control unit (1 of 1)
A/T
ABS MAIN RELAY ANTI-LOCK BRAKE CONTROL UNIT
AIR BAG DIAGNOSTIC UNIT
AIR BAG FUSE
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
COMBINATION SWITCH
CRUISE CONTROL MAIN SWITCH
DATA LINK CONNECTOR (DLC)
DISTRIBUTOR
ELECTRONIC TIME, ALARM CONTROL MODULE
ENG FUSE
ENGINE COMPARTMENT FUSE/RELAY BOX
ENGINE COOLING FAN RELAY
FROM ENGINE COMPARTMENT FUSE/RELAY BOX
FRONT HEATED OXYGEN SENSOR
GRN WIRE
IGNITION COIL
IGNITION SWITCH
INSTRUMENT CLUSTER
LOCK
LOCK ON
LOCK ON IGN 1
M/T
M/T A/T
MAIN RELAY
NCA WIRE
ON IGN 2
PASSENGER COMPARTMENT FUSE BOX
POWERTRAIN CONTROL MODULE (TCM)
R DEF FUSE METER FUSE
REAR WINDOW DEFOGGER RELAY
SHIFT LOCK ACTUATOR
STARTER CLUTCH PEDAL POSITION SWITCH
TO PASSENGER COMPARTMENT FUSE BOX (DIAGRAM 4 OF 4)
TRANSAXLE RANGE SWITCH BACK-UP LIGHT SWITCH
TRANSAXLE RANGE SWITCH CRUISE CONTROL UNIT
TURN SIGNAL SWITCH
VEHICLE SPEED SENSOR (VSS)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> TRANSAXLE RANGE SWITCH CRUISE CONTROL UNIT
