Kia Sephia I facelift (1994-1998) gnd brake sw input brake sw input acc test Wiring diagram
This page shows the only wiring diagram for the component.gnd brake sw input brake sw input acc test, which is found in the car Kia Sephia I facelift (1994-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd brake sw input brake sw input acc test (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 ACTUATOR CTRL ACTUATOR CTRL
19 17 DATA LINK CONNECTOR (CENTER REAR OF ENGINE COMPARTMENT)
A/T
ACTUATOR CTRL CRUISE IND CTRL CRUISE SW ON
BLK WIRE
BLK/BLU (OR BRN/YEL) WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/RED WIRE
BRAKE PEDAL SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
BRN/YEL WIRE
CRUISE CONTROL ACTUATOR (LEFT SIDE OF ENGINE COMPARTMENT)
CRUISE CONTROL INDICATOR (AUTO CRUISE)
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL SWITCH (COMBINATION SWITCH)
CRUISE CONTROL UNIT (BELOW RIGHT SIDE OF DASH, AT KICK PANEL)
ENGINE CONTROLS SYSTEM
GND BRAKE SW INPUT BRAKE SW INPUT ACC TEST
GRN/RED WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ILLUM
INSTRUMENT CLUSTER
J/C 3 (BELOW LEFT SIDE OF I/P, ABOVE FUSE BOX)
J/C 4 (BEHIND RIGHT SIDE OF I/P, BELOW RIGHT FRONT DOOR ACCESS HOLE)
M/T
METER FUSE
NCA WIRE
NEUTRAL POSITION SWITCH (LOWER RIGHT REAR OF TRANSAXLE)
OFF
PASSENGER COMPARTMENT FUSE BOX (BELOW LEFT SIDE OF DASH, AT KICK PANEL)
PNK/BLU WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RESUME/ ACCEL
SET/ COAST
SPEEDOMETER ASSEMBLY
STARTER STARTER SOLENOID
STOP FUSE
TRANSAXLE RANGE SWITCH (ON TOP FRONT OF AUTOMATIC TRANSAXLE)
WHT WIRE
WHT/BLU WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
