Kia Sephia I facelift (1994-1998) egr valve position sensor Wiring diagram
This page shows the only wiring diagram for the component.egr valve position sensor, which is found in the car Kia Sephia I facelift (1994-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram egr valve position sensor (1 of 1)
1.8L
5 4 (1.6L) (1.8L)
BATTERY
BLK WIRE
CRANKSHAFT POSITION SENSOR SHIELD
DISTRIBUTOR IGNITION CONTROL MODULE (ICM)
EGR BOOST SENSOR
EGR PRESSURE SENSOR (1.6L)
EGR VALVE POSITION SENSOR
ENGINE COOLANT TEMPERATURE (ECT) SENSOR
FRONT HEATED OXYGEN SENSOR
FUEL TANK PRESSURE SENSOR
J/C 2 (BELOW CENTER OF I/P)
J/C-1 (BELOW CENTER OF I/P)
MASS AIR FLOW (MAF SENSOR)
OBD-II DATA LINK CONNECTOR
POWERTRAIN CONTROL MODULE (PCM)
REAR HEATED OXYGEN SENSOR
SHIELD
THROTTLE POSITION (TP) SENSOR
TRANSAXLE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (1 of 3) -> EGR VALVE POSITION SENSOR
