Kia Sephia I facelift (1994-1998) eat fail eat test trans fluid temp Wiring diagram

1-2 SHIFT 10 18 DATA LINK CONNECTOR (CENTER REAR OF ENGINE COMPARTMENT) 2-3 SHIFT 3-4 SHIFT LOCK-UP SOLENOID VALVE BLK WIRE BLK/ WHT WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU ORG WIRE BLU WIRE BLU/ YEL WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE PEDAL SWITCH BRN/BLK WIRE BRN/YEL WIRE COOLANT TEMP INP VEH SPD INPUT EAT FAIL EAT TEST TRANS FLUID TEMP ENGINE CONTROL MODULE (BELOW CENTER OF DASH) GRN/RED WIRE GROUND GRY/BLK WIRE HOLD SWITCH (CENTER CONSOLE) HOT AT ALL TIMES HOT IN ON OR START IDLE SWITCH INPUT HOLD IND CTRL PK/NEUT OUTPUT BRAKE INPUT HOLD SW INPUT GROUND IGNITION SWITCH INSTRUMENT CLUSTER SYSTEM J/C LOCK LT GRN WIRE LT GRN/ORG WIRE LT GRN/RED WIRE METER FUSE NCA WIRE ORG/ BLU WIRE ORG/ WIRE PASSENGER COMPARTMENT FUSE BOX ROOM FUSE PULSE GENERATOR RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RUN WIRE SOLENOID VALVE STARTING/ CHARGING SYSTEM STOP FUSE THROT POS INPUT THROTTLE POSITION SENSOR (ON THROTTLE BODY) TRANSAXLE TRANSAXLE RANGE SWITCH (LOWER LEFT OF ENGINE COMPARTMENT, ON TOP OF TRANSAXLE) TRANSMISSION CONTROL MODULE TRANSMISSION FLUID TEMPERATURE SENSOR VEHICLE SPEED SENSOR HOLD INDIC VOLUME AIR FLOW SENSOR (IN AIR CLEANER HOUSING) WHT/BLK WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
