Kia Sephia I facelift (1994-1998) door knob lock switch master power window switch Wiring diagram
This page shows the only wiring diagram for the component.door knob lock switch master power window switch, which is found in the car Kia Sephia I facelift (1994-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door knob lock switch master power window switch (1 of 1)
1.6L
1.8L
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
CLUTCH PEDAL POSITION SWITCH
COMBINATION SWITCH (WIPER, WASHER SWITCH)
CONDENSER FAN MOTOR
CONDENSER FAN RELAY
CRUISE CONTROL SWITCH
CRUISE CONTROL UNIT
DATA LINK CONNECTOR (DLC)
DOOR KNOB LOCK SWITCH MASTER POWER WINDOW SWITCH
ELECTRONIC TIME AND ALARM CONTROL MODULE
ENGINE COMPARTMENT FUSE/RELAY BOX
ENGINE COOLING FAN MOTOR
FLASHER MODULE
FROM J/C 6 (DIAGRAM 3 OF 3)
FRONT HEATED OXYGEN SENSOR
GRY WIRE
IGNITION COIL SHIELD
IGNITION SWITCH
INPUT/TURBINE SPEED SENSOR SHIELD
INSTRUMENT CLUSTER
J/C 3 (BELOW LEFT SIDE OF I/P)
J/C 4 (BEHIND RIGHT SIDE OF I/P)
J/C NO. 5 (BENEATH LEFT FRONT SEAT)
LEFT FRONT DOOR JAMB SWITCH
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT
LIGHT SWITCH
M/T
MAIN RELAY
NEUTRAL POSITION SWITCH
NOT USED
PARK RANGE SWITCH
REAR HEATED OXYGEN SENSOR
REAR HEATED OXYGEN SENSOR (1996 1.6L)
REAR HEATED OXYGEN SENSOR (1997 1.6L)
RIGHT FRONT DOOR JAMB SWITCH
RIGHT FRONT POWER WINDOW SWITCH
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT
SEAT BELT SWITCH
VEHICLE SPEED SENSOR (VSS)
WHT WIRE
Go to component -> Ground distribution circuit (2 of 3) -> DOOR KNOB LOCK SWITCH MASTER POWER WINDOW SWITCH
