Kia Sephia I facelift (1994-1998) 8 10 15 6 idle sw in p/n out coolant temp in engine test Wiring diagram

8 10 15 6 IDLE SW IN P/N OUT COOLANT TEMP IN ENGINE TEST A/T BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE PEDAL SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) BRN/YEL WIRE CLOSED THROTTLE POSITION (TP) SENSOR (TOP LEFT REAR OF ENGINE, ON THROTTLE BODY) CLUTCH PEDAL POSITION SWITCH (BELOW LEFT SIDE OF I/P, ON REAR OF CTRL IGNITION DATA LINK (DLC) CONNECTOR (CENTER REAR OF ENGINE COMPARTMENT) DISTRIBUTOR DISTRIBUTOR ASSEMBLY EGR VALVE POSITION SENSOR (TOP LEFT REAR OF ENGINE) ENGINE COOLANT TEMPERATURE SENSOR (LEFT SIDE OF ENGINE) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRY/BLK WIRE HEATED OXYGEN SENSOR HOT AT ALL TIMES HOT IN ON AND START HOT WITH HEAD OR PARKING LTS ON IGNITION COIL IGNITION CONTROL MODULE (ICM) IGNITION IN IGNITION SWITCH INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM (TACHOMETER) J/C-1 (BELOW CENTER OF I/P) LOCK LT GRN WIRE LT GRN/RED WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE M/T MALFUNCTION INDICATOR METER FUSE NCA WIRE NEUTRAL POSITION SWITCH (LOWER RIGHT REAR OF TRANSAXLE) PASSENGER COMPARTMENT FUSE BOX RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE SENSOR OUT CAMSHAFT SHIFT SIG OUT STOP FUSE SUPPORT BRACKET) TAIL FUSE TPS IN TRANSMISSIONS SYSTEM VEHICLE SPEED OUTPUT WHT/GRN WIRE WHT/RED WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/WHT WIRE
