Kia Seltos I facelift (2022-2024) w/ long term load auto cut relay energized Wiring diagram
This page shows the only wiring diagram for the component.w/ long term load auto cut relay energized, which is found in the car Kia Seltos I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ long term load auto cut relay energized (1 of 1)
'B' OUTPUT
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
GND 2
GRN WIRE
GRY WIRE
HEAD-UP DISPLAY
HOT IN ON OR START
HUD SWITCH
ICU JUNCTION BLOCK
ICU-E
ILL
ISG FUSE
LDC B+
LOW DC-DC CONVERTER
M-CAN HIGH
M-CAN LOW
MEMORY 2 FUSE
MEMORY POWER
MULTIMEDIA FUSE
ON/START INPUT
ORG/ WIRE
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
RED (OR GRY) WIRE
RED WIRE
RED/BLK WIRE
SWITCH SIGNAL
W/ AMP
W/ LONG TERM LOAD AUTO CUT RELAY ENERGIZED
W/ NAVIGATION
W/O AMP
WHT WIRE
Go to component -> Head-up display circuit -> W/ LONG TERM LOAD AUTO CUT RELAY ENERGIZED
