Kia Seltos I facelift (2022-2024) sound mood lamp Wiring diagrams
This page contains all the electrical diagrams for the component. sound mood lamp, in which he is found in the car Kia Seltos I facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
sound mood lamp wiring diagram (1 of 4)
'B' OUTPUT
A/V, NAVIGATION HEAD UNIT
ACC/ON INPUT
ACC/ON OUTPUT
AMP FUSE
AUX, USB JACK
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DTC
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
HOT W/ LONG TERM LOAD AUTO CUT RELAY ENERGIZED
I-CAN HIGH
I-CAN LOW
ICU JUNCTION BLOCK
ICU-D
ICU-E
ILL
ILL (+) M-CAN HIGH
ILL (-) M-CAN LOW
ISG FUSE
ISG START
LOW DC-DC CONVERTER (AMP)
MEMORY POWER
MEMORY PWR
MIC 1 MIC (-)
MIC 2 MIC (-)
MODULE 2 FUSE
MODULE 5 FUSE
MTS KEYPAD SIG
MULTI MEDIA FUSE
NCA WIRE
ON/START INPUT
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
SOUND MOOD LAMP
STARTING/ CHARGING SYSTEM
USB D (-) USB VCC
USB D-
USB GND
USB VCC
WHT WIRE
Go to component -> Navigation circuit, w/ amplifier (4 of 4) -> SOUND MOOD LAMP
sound mood lamp wiring diagram (2 of 4)
2.0L
A/V, NAVIGATION HEAD UNIT
ACC/ON IN
ACC/ON OUT
AMP
AMP OUT
AUDIO
B+ OUT
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
DRIVER DOOR MOOD LAMP
E/R JUNCTION BLOCK
FROM ICU JUNCTION BLOCK (DIAGRAM 5 OF 11)
FROM ICU JUNCTION BLOCK (DIAGRAM 7 OF 11)
GRN WIRE
GRY WIRE
ISG START
LOW DC-DC CONVERTER
MEMORY PWR
ON/START IN
PASSENGER DOOR MOOD LAMP
PCM (2.0L) ECM (1.6L TURBO)
RED WIRE
RED/BLK WIRE
SOUND MOOD LAMP
START RELAY
TO ICU JUNCTION BLOCK (DIAGRAM 9 OF 11)
W/ AMP
W/ NAVIGATION
W/O AMP
W/O NAVIGATION
Go to component -> Power distribution circuit (11 of 11) -> SOUND MOOD LAMP
sound mood lamp wiring diagram (3 of 4)
A/C CONTROL MODULE
A/V, NAVIGATION HEAD UNIT
ATM SHIFT LEVER INDICATOR
AUDIO
AUTOMATIC A/C
AUX, USB JACK
BLU WIRE
BLU/ORG WIRE
CLOCKSPRING
CRASH PAD SWITCH
DRIVER DOOR MOOD LAMP
ELECTRIC PARKING BRAKE SWITCH
FROM LOW DC-DC CONVERTER (DIAGRAM 11 OF 11)
FROM LOW DC-DC CONVERTER (W/O AMP) (DIAGRAM 11 OF 11)
GRY WIRE
HEAD-UP DISPLAY
ICU-E
ICU-G
INSTRUMENT CLUSTER
ISG FUSE
LEFT BLIND-SPOT COLLISION WARNING UNIT
LEFT CONSOLE SWITCH
LEFT STEERING WHEEL REMOTE CONTROL SWITCH
MANUAL A/C
ORG/ WIRE
OVERHEAD CONSOLE LAMP
PASSENGER DOOR MOOD LAMP
PNK WIRE
RED WIRE
RED/BLK WIRE
RIGHT BLIND-SPOT COLLISION WARNING UNIT
RIGHT CONSOLE SWITCH
RIGHT STEERING WHEEL REMOTE CONTROL SWITCH
SOUND MOOD LAMP
STEERING WHEEL)
TO WIRELESS CHARGER INDICATOR (DIAGRAM 4 OF 11)
W/ AMP
W/ NAVIGATION
W/ NAVIGATION, AUDIO DISPLAY
W/O AMP
W/O NAVIGATION, AUDIO DISPLAY
YEL WIRE
Go to component -> Power distribution circuit (9 of 11) -> SOUND MOOD LAMP
sound mood lamp wiring diagram (4 of 4)
'B' OUTPUT
A/V, NAVIGATION HEAD UNIT
ACC/ON INPUT
ACC/ON OUTPUT
AMP FUSE
AUX, USB JACK
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DTC
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
HOT W/ LONG TERM LOAD AUTO CUT RELAY ENERGIZED
I-CAN HIGH
I-CAN LOW
ICU JUNCTION BLOCK
ICU-D
ICU-E
ILL
ILL (+) M-CAN HIGH
ILL (-) M-CAN LOW
ISG FUSE
ISG START
LOW DC-DC CONVERTER (AMP)
MEMORY POWER
MEMORY PWR
MIC 1 MIC (-)
MIC 2 MIC (-)
MODULE 2 FUSE
MODULE 5 FUSE
MTS KEYPAD SIG
MULTI MEDIA FUSE
NCA WIRE
ON/START INPUT
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
SOUND MOOD LAMP
STARTING/ CHARGING SYSTEM
USB D (-) USB VCC
USB D-
USB GND
USB VCC
WHT WIRE
Go to component -> Radio circuit, w/ navigation & amplifier (4 of 4) -> SOUND MOOD LAMP
