Kia Seltos I facelift (2022-2024) smart gear actuator Wiring diagrams
This page contains all the electrical diagrams for the component. smart gear actuator, in which he is found in the car Kia Seltos I facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
smart gear actuator wiring diagram (1 of 3)
2.0L
ATM SHIFT LEVER
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
C-CAN HIGH
C-CAN LOW
CAN 3-HIGH
CAN 3-LOW
CAN 4-HIGH
CAN 4-LOW
CCP-CAN HIGH
CCP-CAN LOW
DCT
ESC MODULE
ESC UNIT
FORWARD COLLISION AVOIDANCE ASSIST UNIT
GRN WIRE
GRN/ORG WIRE
GRY/ORG WIRE
L-CAN CHECK CONNECTOR
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
RED WIRE
SMART GEAR ACTUATOR
W/ EPB W/O EPB
WHT WIRE
WHT/BLK WIRE
Go to component -> Computer data lines circuit (5 of 5) -> SMART GEAR ACTUATOR
smart gear actuator wiring diagram (2 of 3)
ACC RELAY
BLK WIRE
BLOWER RELAY
BRAKE FLUID LEVEL SENSOR
COOLING FAN 1 RELAY
COOLING FAN MOTOR
DATA LINK CONNECTOR
E/R JUNCTION BLOCK
E/R-D
EXTERNAL BUZZER
FORWARD COLLISION AVOIDANCE ASSIST UNIT
FRONT WIPER (LOW) RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER MOTOR
HORN
IBU
ICU JUNCTION BLOCK
ICU-B
IPS CONTROL MODULE
LEFT CENTER FORWARD PARKING DISTANCE WARNING SENSOR
LEFT FORWARD PARKING DISTANCE WARNING SENSOR
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT SIDE MARKER LAMP
LEFT SIDE REPEATER LAMP
MDPS UNIT
NCA WIRE
ORG/ WIRE
PTC HEATER
RIGHT CENTER FORWARD PARKING DISTANCE WARNING SENSOR
RIGHT FORWARD PARKING DISTANCE WARNING SENSOR
SMART GEAR ACTUATOR
STOP LAMP SWITCH
W/ S/MARKER LAMP
W/ SMART KEY
W/O LED W/ LED
W/O S/MARKER LAMP
W/O SMART KEY W/ SMART KEY
Go to component -> Ground distribution circuit (3 of 6) -> SMART GEAR ACTUATOR
smart gear actuator wiring diagram (3 of 3)
2.0L
ABS 2 FUSE
ALT FUSE
ALTERNATOR
AMS FUSE
B+2 FUSE
B+3 FUSE
B+4 FUSE
B+5 FUSE
BATTERY
BATTERY JUNCTION BLOCK
BATTERY SENSOR
BLK WIRE
BLOWER FUSE
BLOWER RELAY
BLU WIRE
COOLING FAN 1 FUSE
COOLING FAN 1 RELAY
COOLING FAN 2 FUSE
COOLING FAN 2 RELAY
EPB 1 FUSE
EPB 2 FUSE
ESC MODULE
FRONT DEICER BOX
FRT HTD FUSE
FUEL PUMP FUSE
FUEL PUMP RELAY
GRN WIRE
GRY WIRE
MDPS FUSE
MDPS UNIT
MULTI FUSE 1
MULTI FUSE 2
ORG/ WIRE
PNK WIRE
RED WIRE
SGA FUSE
SMART GEAR ACTUATOR
START MOTOR
START RELAY
TO ICU JUNCTION BLOCK (DIAGRAM 5 OF 11)
TO ICU JUNCTION BLOCK (DIAGRAM 7 OF 11)
TO ICU JUNCTION BLOCK (DIAGRAM 8 OF 11)
TO IGNITION SWITCH (DIAGRAM 10 OF 11)
TO PCB BLOCK (DIAGRAM 3 OF 11)
TO POWER OUTLET FUSE (DIAGRAM 2 OF 11)
W/ EPB
W/ SMART KEY
W/O SMART KEY
WHT WIRE
Go to component -> Power distribution circuit (1 of 11) -> SMART GEAR ACTUATOR
