Kia Seltos I facelift (2022-2024) right center position lamp Wiring diagrams
This page contains all the electrical diagrams for the component. right center position lamp, in which he is found in the car Kia Seltos I facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right center position lamp (1 of 3)
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN/BLK WIRE
BRN/RED WIRE
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
ICU JUNCTION BLOCK
ICU-B
ICU-D
IPS 12 CTRL
IPS 13 CTRL
IPS CONTROL MODULE
LEFT
LEFT CENTER POSITION LAMP
LEFT LICENSE LAMP
LEFT RIGHT
LEFT SIDE MARKER LAMP
NCA WIRE
RED/ORG WIRE
RIGHT
RIGHT CENTER POSITION LAMP
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP (OUT)
SIDE MARKER LAMP
STOP LAMP
TAIL LAMP
TURN LAMP
W/ LED
W/ LED W/O LED
W/O LED
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 4) -> RIGHT CENTER POSITION LAMP
Wiring diagram right center position lamp (2 of 3)
2.0L
BLK WIRE
BLK/BLU WIRE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR MOOD LAMP
DRIVER POWER OUTSIDE MIRROR
DRIVER RECLINING LIMIT SWITCH
DRIVER SAFETY POWER WINDOW MODULE
DRIVER SEAT BELT BUCKLE SWITCH
DRIVER SEAT MANUAL SWITCH
DRIVER SMART KEY OUTSIDE HANDLE
ESC MODULE
FRONT DEICER
HOOD SWITCH
ICU-D
IVT
LEFT CENTER POSITION LAMP
NCA WIRE
NOZZLE HEATER
PCM
POWER OUTSIDE MIRROR SWITCH
POWER WINDOW MAIN SWITCH
RED WIRE
RIGHT CENTER POSITION LAMP
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT SIDE MARKER LAMP
RIGHT SIDE REPEATER LAMP
W/ AUTO UP/DOWN, SAFETY
W/ CENTER POSITION LAMP
W/ DRIVER AUTO DOWN
W/ S/ MARKER LAMP
W/O CENTER POSITION LAMP
W/O EPB W/ EPB
W/O LED W/ LED
W/O S/ MARKER LAMP
WASHER LEVEL MOTOR
WASHER MOTOR
YEL WIRE
Go to component -> Ground distribution circuit (4 of 6) -> RIGHT CENTER POSITION LAMP
Wiring diagram right center position lamp (3 of 3)
B/UP LAMP
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
DRIVER POWER OUTSIDE MIRROR
ELECTRO- CHROMIC MIRROR
FROM B+2 FUSE (DIAGRAM 1 OF 11)
GLOVE BOX LAMP)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
GRY/ORG WIRE
HIGH MOUNTED STOP LAMP
HMSL
ICU-B
ICU-C
ICU-D
ICU-F
ICU-G
IPS 11 CTRL
IPS 12 CTRL
IPS 17 CTRL
IPS 4 CTRL
IPS 5 CTRL
IPS 6 CTRL
IPS 8 CTRL
IPS 9 CTRL
IPS CONTROL MODULE
LAMP LOAD AUTOCUT
LEFT CENTER POSITION LAMP
LEFT FRONT VANITY LAMP
LEFT HEADLAMP
LEFT REAR COMBINATION LAMP (IN)
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR POWER WINDOW SWITCH
LEFT SIDE MARKER LAMP
LEFT SIDE REPEATER LAMP
LF EXT TAIL
LH DEDI DRL
LH FRT T/SIG
LH H/LP LOW
LH RR T/SIG
LUGGAGE LAMP
NCA WIRE
OVERHEAD CONSOLE LAMP
PASSENGER POWER WINDOW SWITCH
POWER WINDOW MAIN SWITCH
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RF EXT TAIL
RH DEDI DRL
RH H/LP HI
RH STOP LAMP
RIGHT CENTER POSITION LAMP
RIGHT FRONT VANITY LAMP
RIGHT HEADLAMP
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT REAR POWER WINDOW SWITCH
RIGHT SIDE MARKER LAMP
ROOM LAMP
TO ICU JUNCTION BLOCK (DIAGRAM 9 OF 11)
W/O LED W/ LED
WHT WIRE
Go to component -> Power distribution circuit (8 of 11) -> RIGHT CENTER POSITION LAMP
