Kia Seltos I facelift (2022-2024) right center parking distance warning reverse sensor Wiring diagram
This page shows the only wiring diagram for the component.right center parking distance warning reverse sensor, which is found in the car Kia Seltos I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right center parking distance warning reverse sensor (1 of 1)
2.0L
AMP
BLK WIRE
ELECTRO MAGNETIC CLUTCH MOTOR SHIELD
FUEL PUMP CONTROL MODULE
FUEL SENDER, FUEL PUMP MOTOR
GRY WIRE
HIGH MOUNTED STOP LAMP
ICU JUNCTION BLOCK IPS CONTROL MODULE
LEFT BLIND-SPOT COLLISION WARNING UNIT
LEFT CENTER PARKING DISTANCE WARNING REVERSE SENSOR
LEFT LICENSE LAMP
LEFT PARKING DISTANCE WARNING REVERSE SENSOR
LEFT REAR COMBINATION LAMP (IN)
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR DOOR LOCK ACTUATOR
LEFT REAR POWER WINDOW SWITCH
NCA WIRE
NOT USED
ORG/ WIRE
PASSENGER OCCUPANT DETECTION SENSOR
PASSENGER SEAT BELT BUCKLE SENSOR
REAR DEFOGGER
REAR SEAT WARMER MODULE
REAR WIPER MOTOR
RIGHT BLIND-SPOT COLLISION WARNING UNIT
RIGHT CENTER PARKING DISTANCE WARNING REVERSE SENSOR
RIGHT LICENSE LAMP
RIGHT PARKING DISTANCE WARNING REVERSE SENSOR
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT REAR DOOR LOCK ACTUATOR
SRS CONTROL MODULE
TAIL GATE SWITCH
TAILGATE LATCH
Go to component -> Ground distribution circuit (6 of 6) -> RIGHT CENTER PARKING DISTANCE WARNING REVERSE SENSOR
