Kia Seltos I facelift (2022-2024) right center forward parking distance warning sensor Wiring diagram
This page shows the only wiring diagram for the component.right center forward parking distance warning sensor, which is found in the car Kia Seltos I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right center forward parking distance warning sensor (1 of 1)
ACC RELAY
BLK WIRE
BLOWER RELAY
BRAKE FLUID LEVEL SENSOR
COOLING FAN 1 RELAY
COOLING FAN MOTOR
DATA LINK CONNECTOR
E/R JUNCTION BLOCK
E/R-D
EXTERNAL BUZZER
FORWARD COLLISION AVOIDANCE ASSIST UNIT
FRONT WIPER (LOW) RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER MOTOR
HORN
IBU
ICU JUNCTION BLOCK
ICU-B
IPS CONTROL MODULE
LEFT CENTER FORWARD PARKING DISTANCE WARNING SENSOR
LEFT FORWARD PARKING DISTANCE WARNING SENSOR
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT SIDE MARKER LAMP
LEFT SIDE REPEATER LAMP
MDPS UNIT
NCA WIRE
ORG/ WIRE
PTC HEATER
RIGHT CENTER FORWARD PARKING DISTANCE WARNING SENSOR
RIGHT FORWARD PARKING DISTANCE WARNING SENSOR
SMART GEAR ACTUATOR
STOP LAMP SWITCH
W/ S/MARKER LAMP
W/ SMART KEY
W/O LED W/ LED
W/O S/MARKER LAMP
W/O SMART KEY W/ SMART KEY
Go to component -> Ground distribution circuit (3 of 6) -> RIGHT CENTER FORWARD PARKING DISTANCE WARNING SENSOR
