Kia Seltos I facelift (2022-2024) rear washer motor switch power Wiring diagram
This page shows the only wiring diagram for the component.rear washer motor switch power, which is found in the car Kia Seltos I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear washer motor switch power (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
GND (BCM)
GRN WIRE
GRY WIRE
HOT IN ON
IBU (RIGHT SIDE OF HVAC CASE)
ICM RELAY BOX
ICU JUNCTION BLOCK
ICU-D
ICU-E
MULTI- FUNCTION SWITCH
ON INPUT
PNK WIRE
REAR WASHER
REAR WASHER MOTOR SWITCH POWER
REAR WASHER SIG
REAR WIPER MOTOR
REAR WIPER RELAY
REAR WIPER RLY CTRL
REAR WIPER SW SIG
REAR WIPER SWITCH SIGNAL
RED WIRE
WASHER FUSE
WASHER MOTOR
WIPER RR FUSE
WIPER, LIGHT GND
Go to component -> Rear wiper/washer circuit -> REAR WASHER MOTOR SWITCH POWER
