Kia Seltos I facelift (2022-2024) memory power p-can high Wiring diagrams
This page contains all the electrical diagrams for the component. memory power p-can high, in which he is found in the car Kia Seltos I facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram memory power p-can high (1 of 2)
2.0L
A/C PRESSURE TRANSDUCER
APT GND
APT SIG
APT/RPS/BPS P APT SPLY
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
C/FAN RLY CTRL HIGH
C/FAN RLY CTRL LOW
COMPUTER DATA LINES SYSTEM
COOLING FAN 1 FUSE
COOLING FAN 1 RELAY
COOLING FAN 2 FUSE
COOLING FAN 2 RELAY
COOLING FAN MOTOR
E/R JUNCTION BLOCK
E/R-A
E/R-D
ECT SENS SIG
ECU 3 FUSE
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
FAN PWM ECT SENS GND
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ MAIN RELAY ENERGIZED
MEMORY POWER P-CAN HIGH
MULTI FUSE 2
ORG/ WIRE
P-CAN LOW
PCB BLOCK
PCM (2.0L) ECM (1.6L TURBO)
RED WIRE
RED/BLK WIRE
SENSOR 2 FUSE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Cooling fan circuit -> MEMORY POWER P-CAN HIGH
Wiring diagram memory power p-can high (2 of 2)
2.0L
A/C PRESSURE TRANSDUCER
A/CON RLY CTRL
APT SIG
APT SPLY APT/RPS/BPS POWER APT GND
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
C/FAN RLY CTRL HIGH
C/FAN RLY CTRL LOW
COMPUTER DATA LINES SYSTEM
COOLING FAN 1 FUSE
COOLING FAN 1 RELAY
COOLING FAN 2 FUSE
COOLING FAN 2 RELAY
COOLING FAN MOTOR
E/R JUNCTION BLOCK
E/R-A
ECT SENS GND
ECT SENS SIG
ECU 3 FUSE
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
FAN PWM
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
MEMORY POWER P-CAN HIGH
MULTI FUSE 2
ORG/ WIRE
P-CAN LOW
PCB BLOCK
PCM (2.0L) ECM (1.6L TURBO)
RED WIRE
RED/BLK WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Manual a/c circuit (4 of 4) -> MEMORY POWER P-CAN HIGH
