Kia Seltos I facelift (2022-2024) lock/unlock switch Wiring diagram
This page shows the only wiring diagram for the component.lock/unlock switch, which is found in the car Kia Seltos I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lock/unlock switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DOOR
DOOR LOCK IND
DOOR LOCKS SYSTEM
DOWN
GRN WIRE
GRY WIRE
GRY/ORG WIRE
ILL
LEFT REAR POWER WINDOW MOTOR
LOCK
LOCK/UNLOCK SWITCH
ORG/ WIRE
PASSENGER POWER WINDOW MOTOR
PASSENGER POWER WINDOW SWITCH
PNK WIRE
RED WIRE
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH
UNLOCK
W/LOCK
WHT WIRE
YEL WIRE
Go to component -> Power windows circuit, w/ auto up/down & safety power windows (2 of 2) -> LOCK/UNLOCK SWITCH
