Kia Seltos I facelift (2022-2024) key lock door lock Wiring diagrams
This page contains all the electrical diagrams for the component. key lock door lock, in which he is found in the car Kia Seltos I facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram key lock door lock (1 of 2)
AJAR
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BURGLAR ALARM HORN RELAY CTRL SW
DOOR LOCK
DOOR UNLK
DRIVER DOOR LOCK ACTUATOR
DRV DR KEY UNLK SIG
DRV DR LK/UNLK SIG
DRV DR SW
DRV/PASS DR KEY LK SIG
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOOD
ICU JUNCTION BLOCK
ICU-B
ICU-C
ICU-D
ICU-F
IPS CONTROL MODULE
KEY LOCK DOOR LOCK
KEY UNLK
KEY UNLK KEY LOCK
LR DR LK/UNLK SIG
ORG/ WIRE
PASS DR KEY UNLK SIG
PASS DR LK/UNLK SIG
PASS DR SW
PASSENGER DOOR LOCK ACTUATOR
PNK/BLK WIRE
RED WIRE
RR DR -
RR DR LR DR LK/UNLK SW SW SIG
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Forced entry circuit (2 of 3) -> KEY LOCK DOOR LOCK
Wiring diagram key lock door lock (2 of 2)
AJAR
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BURGLAR ALARM HORN RELAY CTRL SW
DOOR LOCK
DOOR UNLK
DRIVER DOOR LOCK ACTUATOR
DRV DR KEY UNLK SIG
DRV DR LK/UNLK SIG
DRV DR SW
DRV/PASS DR KEY LK SIG
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOOD
ICU JUNCTION BLOCK
ICU-B
ICU-C
ICU-D
ICU-F
IPS CONTROL MODULE
KEY LOCK DOOR LOCK
KEY UNLK
KEY UNLK KEY LOCK
LR DR LK/UNLK SIG
ORG/ WIRE
PASS DR KEY UNLK SIG
PASS DR LK/UNLK SIG
PASS DR SW
PASSENGER DOOR LOCK ACTUATOR
PNK/BLK WIRE
RED WIRE
RR DR -
RR DR LR DR LK/UNLK SW SW SIG
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power door locks circuit (2 of 3) -> KEY LOCK DOOR LOCK
