Kia Seltos I facelift (2022-2024) high pass seat belt buckle sens Wiring diagram
This page shows the only wiring diagram for the component.high pass seat belt buckle sens, which is found in the car Kia Seltos I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high pass seat belt buckle sens (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER CURTAIN AIR BAG
DRIVER FRONT SIDE IMPACT SENSOR
DRIVER SEAT BELT ANCHOR PRETENSIONER
DRIVER SEAT BELT PRETENSIONER
DRIVER SIDE AIR BAG
DRIVER SIDE IMPACT PRESSURE SENSOR
GRN WIRE
GROUND
GRY WIRE
HIGH PASS SEAT BELT BUCKLE SENS
ORG/ WIRE
PASSENGER CURTAIN AIR BAG
PASSENGER FRONT SIDE IMPACT SENSOR
PASSENGER SEAT BELT ANCHOR PRETENSIONER
PASSENGER SEAT BELT BUCKLE SENSOR
PASSENGER SEAT BELT PRETENSIONER
PASSENGER SIDE IMPACT PRESSURE SENSOR
PNK WIRE
RED WIRE
SRS CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> HIGH PASS SEAT BELT BUCKLE SENS
