Kia Seltos I facelift (2022-2024) drl opt in Wiring diagram
This page shows the only wiring diagram for the component.drl opt in, which is found in the car Kia Seltos I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drl opt in (1 of 1)
"P" POSITION SW
ACC/ON INPUT
ANTI-THEFT SYSTEM
AUTO LIGHT SENS GND
AUTO LIGHT SENS SIG
AUTO LIGHT SENS SPLY
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BRN WIRE
BURGLAR ALARM RLY
COIL
COMPUTER DATA LINES SYSTEM
DRIVER DOOR LOCK/UNLOCK SW
DRL OPT IN
EXTERNAL BUZZER
FOG LAMP SW I/P
FRONT WIPER LOW B/UP SWITCH SIG
FRONT WIPER RELAY CONTROL (HIGH) REAR WIPER RLY CTRL
FRONT WIPER RELAY CONTROL LOW
GRN WIRE
GRY WIRE
HEADLAMP HIGH SW IN
HEADLIGHTS SYSTEM
IBU (RIGHT SIDE OF HVAC CASE)
INT/VOL SW
KEY ILL OUT
KEY IN SW
KEY INTERLOCK
LIGHT SW SIG
LIN PDW
NAVIGATION SYSTEM
ON INPUT
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PASSENGER DOOR LOCK/UNLOCK SW
PDW OPTION
PDW SWITCH IND
PDW SWITCH MODE
PDW-F PWR
PDW-R PWR
PNK WIRE
POWER TOPS SYSTEM
RAIN SENSOR SIG
REAR WIPER LOW B/UP SWITCH SIG
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
SHIFT INTERLOCK SYSTEM
SHIFT-LOCK SOL
STARTING/CHARGING SYSTEM
STOP LAMP SW
SUNROOF OPEN SWITCH INPUT
W/ SMART KEY
W/O SMART KEY
WHT WIRE
WHT/BLK WIRE
WIPER B/UP SWITCH SIG
WIPER BLADE POSITION
WIPER, LIGHT GROUND
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Integrated control unit circuit (2 of 2) -> DRL OPT IN
