Wiring diagram apt sply apt/rps/bps power apt gnd (1 of 2)
2.0L
A/C PRESSURE TRANSDUCER
A/CON RLY CTRL
APT SIG
APT SPLY APT/RPS/BPS POWER APT GND
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
C/FAN RLY CTRL HIGH
C/FAN RLY CTRL LOW
COMPUTER DATA LINES SYSTEM
COOLING FAN 1 FUSE
COOLING FAN 1 RELAY
COOLING FAN 2 FUSE
COOLING FAN 2 RELAY
COOLING FAN MOTOR
E/R JUNCTION BLOCK
E/R-A
ECT SENS SIG
ECU 3 FUSE
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
FAN PWM ECT SENS GND
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
MEMORY POWER
MULTI FUSE 2
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCB BLOCK
PCM (2.0L) ECM (1.6L TURBO)
RED WIRE
RED/BLK WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Automatic a/c circuit (4 of 4) -> APT SPLY APT/RPS/BPS POWER APT GND
Wiring diagram apt sply apt/rps/bps power apt gnd (2 of 2)
2.0L
A/C PRESSURE TRANSDUCER
A/CON RLY CTRL
APT SIG
APT SPLY APT/RPS/BPS POWER APT GND
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
C/FAN RLY CTRL HIGH
C/FAN RLY CTRL LOW
COMPUTER DATA LINES SYSTEM
COOLING FAN 1 FUSE
COOLING FAN 1 RELAY
COOLING FAN 2 FUSE
COOLING FAN 2 RELAY
COOLING FAN MOTOR
E/R JUNCTION BLOCK
E/R-A
ECT SENS GND
ECT SENS SIG
ECU 3 FUSE
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
FAN PWM
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
MEMORY POWER P-CAN HIGH
MULTI FUSE 2
ORG/ WIRE
P-CAN LOW
PCB BLOCK
PCM (2.0L) ECM (1.6L TURBO)
RED WIRE
RED/BLK WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Manual a/c circuit (4 of 4) -> APT SPLY APT/RPS/BPS POWER APT GND
