Kia Sedona III (2014-2020) scg lcd temp Wiring diagram
This page shows the only wiring diagram for the component.scg lcd temp, which is found in the car Kia Sedona III (2014-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram scg lcd temp (1 of 1)
ACTIVE ECO/ DRIVE MODE SWITCH
ALTERNATOR (L)
ANTI-THEFT SYSTEM
AUTO HIGH BEAM
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CIRCUIT
COMPUTER DATA LINES SYSTEM
CONSOLE SWITCH
CONSTANT CURRENT
CRUISE CONTROL SYSTEM
CRUISE IND
D OUT
DIAL LCD ILL
ECO IND
ECO/DMS SWITCH
EXTERNAL MEMORY
FOG LAMP IND
FUEL
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HIGH BEAM IND
IMMO IN
IMMO IND
IN (-)
IND
INSTRUMENT CLUSTER
INTERFACE
LDWS
LEFT TURN IND
LOW BEAM IND
LT GRN WIRE
MICOM
N OUT
NAVIGATION SYSTEM SEATS SYSTEM
OIL PRESSURE
OIL PRESSURE SWITCH
ORG/ WIRE
P OUT
PARKING BRAKE
PNK WIRE
POINTER ILL
R - OUT
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RHEOSTAT DOWN INPUT
RHEOSTAT UP INPUT
RIGHT TURN IND
S OUT
SCG LCD
SCG LCD TEMP
SET IND
SPEED OUT
SPEEDOMETER
STARTING/CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TAIL ON IND
TFT LCD (7 INCH)
TFT LCD DRIVE
TO LOW FUEL IND (DIAGRAM 3 OF 3)
TRANSMISSIONS SYSTEM
TRIP SWITCH
WASHER LOW
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
WIPER/WASHER SYSTEM
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Instrument cluster circuit, w/ supervision (1 of 3) -> SCG LCD TEMP
