Kia Sedona III (2014-2020) lighting switch ground Wiring diagram
This page shows the only wiring diagram for the component.lighting switch ground, which is found in the car Kia Sedona III (2014-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lighting switch ground (1 of 1)
AUTO
AUTO HIGH BEAM IND
AUTO LIGHT SENSOR
AUTO LIGHT, PHOTO SENSOR (TOP CENTER OF DASH)
B-CAN HIGH
B-CAN LOW
BCM (RIGHT END OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
CIRCUIT
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DIMMER
FOG LAMP IND
FOG LAMP SWITCH
FRONT FOG LAMP
GROUND
GRY WIRE
GRY/ORG WIRE
HEAD (LOW)
HEADLAMP HIGH SWITCH
HEADLAMP LOW BACKUP SWITCH
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON OR START
I/P-E
I/P-G
INSTRUMENT CLUSTER
INTERFACE
LEAK CURRENT AUTO CUT DEVICE
LIGHTING SWITCH GROUND
LIGHTING SWITCH SIGNAL
LOW BEAM IND
M-CAN TRANSCEIVER
MEMORY 2 FUSE
MEMORY POWER
MICOM
MULTI- FUNCTION SWITCH
ORG/ WIRE
PASS
POWER
RED WIRE
RED/BLK WIRE
RIGHT END OF DASH)
SIGNAL
SMART JUNCTION BLOCK
TAIL
TAIL ON IND
WHT/BLK WIRE
Go to component -> Autolamps circuit (2 of 2) -> LIGHTING SWITCH GROUND
