Premium radio circuit, without navigation with rear seat entertainment for Kia Sedona II facelift (2010-2014)

1 2 3 4 5 6 7 8 SPEED ILL (+) REMOTE ANTENNA BATTERY VOLTAGE A GND ACC/ON INPUT ILL (-) GROUND AM/FM FEEDER CABLE AUDIO AUDIO FUSE AUDIO L+ AUDIO R- AUDIO REMOTE CONTROL BEC-IM BLK RED/ WIRE BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE CLOCK- SPRING COMPUTER DATA LINES SYSTEM INTERIOR LIGHTS SYSTEM DASH) FUSE GRN WIRE GRN/BLK WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START IG 1 FUSE ILL IPM (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH) J/C JMC J/C JMD MODE MULTIFUNCTION SWITCH MUTE VOL UP VOL DOWN NCA WIRE PNK WIRE PNK/BLK WIRE REAR REMOTE SURROUND ON/OFF RED WIRE RED/BLK WIRE ROOF ANTENNA CIRCUIT (ROOF) RSE MODULE (UNDER REAR ROOF CONSOLE) RSE-IN GND RSE-R-CH-IN RSE-L-CH-IN STEERING WHEEL) V GND VIDEO JACK VIDEO+ WHT WIRE WHT/BLK WIRE XM-FEEDER CABLE YEL WIRE YEL/BLK WIRE

AMP (ON FLOOR, UNDER FRONT AMP FUSE AUDIO AUX DET AUX DET GROUND AUX R-IN AUX L IN AUX R IN AUX REF AUX REF L-IN ILL (+) BEC-IF BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE DOOR SPEAKER DRIVER DOOR SPEAKER DRIVER TWEETER SPEAKER FL (-) FR (-) FRONT CENTER SPEAKER (+) GRN WIRE GROUND HOT AT ALL TIMES IPM (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH) LEFT REAR AMP LEFT SLIDING MEDIA JACK MIC - NCA WIRE ON/START INPUT ORG/ WIRE PASSENGER DOOR SPEAKER PASSENGER TWEETER SPEAKER PASSENGER'S SEAT) REAR CENTER RED WIRE RED/BLK WIRE REMOTE GROUND RHTWT (-) LHTWT (-) WOOFER SPEAKER 2(-) WOOFER SPEAKER 1(-) RIGHT REAR AMP RIGHT SLIDING RL (+) RR (-) S/WHEEL REMOTE SPEAKER SPEAKER (JBL) USB D- USB D-/IPOD TX USB D+/IPOD USB/IPOD GND USB/IPOD GND USB/IPOD VOD WHT WIRE WOOFER SPEAKER YEL WIRE YEL/BLK WIRE
