Kia Sedona II facelift (2010-2014) stop lamp switch signal +ecu vcc vcc Wiring diagrams
This page contains all the electrical diagrams for the component. stop lamp switch signal +ecu vcc vcc, in which he is found in the car Kia Sedona II facelift (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram stop lamp switch signal +ecu vcc vcc (1 of 2)
ABS 1 FUSE
ABS 2 FUSE
ABS IND.
BEC-FE
BEC-FF
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
CLOSE WITH BRAKE PEDAL DEPRESSED
COMPUTER DATA LINES SYSTEM
EBD IND
ESC FUNCTION
ESC MODULE (A/T) (LEFT REAR OF ENGINE COMPT)
ESC OFF SWITCH
FAM (FRONT AREA MODULE) (LEFT FRONT OF ENGINE COMPT)
GRN WIRE
GRN/BLK WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT WHEEL SENSOR (ON LEFT FRONT STEERING KNUCKLE)
LEFT REAR WHEEL SENSOR (ON LEFT REAR BRAKE BACKING PLATE)
NCA WIRE
OPEN WITH BRAKE PEDAL DEPRESSED
ORG/ WIRE
PARKING BRAKE SIGNAL ESC IND
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PNK WIRE
RED WIRE
RED/BLK WIRE
RFP-MOTOR C-CAN LOW
RIGHT REAR WHEEL SENSOR (ON RIGHT REAR BRAKE BACKING PLATE)
SIGNAL
STOP LAMP FUSE
STOP LAMP SWITCH
STOP LAMP SWITCH SIGNAL +ECU VCC VCC
STOP SIGNAL FUSE
VBATT C-CAN HIGH WHL SPD SNSR OUT
VCC VCC SIGNAL
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, with esc (1 of 2) -> STOP LAMP SWITCH SIGNAL +ECU VCC VCC
Wiring diagram stop lamp switch signal +ecu vcc vcc (2 of 2)
30 BCM-FE
ABS 1 FUSE
ABS 2 FUSE
ABS CONTROL MODULE (AT LEFT REAR OF ENGINE COMPT)
ABS FUSE
ABS IND.
BEC-FE
BEC-FF FAM (FRONT AREA MODULE) (LEFT FRONT OF ENGINE COMPT)
BEC-IF
BEC-IM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CLG-B
CLOSE WITH BRAKE PEDAL DEPRESSED
COMPUTER DATA LINES SYSTEM
EBD IND
FAM (FRONT AREA MODULE) (LEFT FRONT OF ENGINE COMPT)
FAM (LEFT FRONT OF ENGINE COMPT)
GRN WIRE
GRN/BLK WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IG 1 FUSE
INSTRUMENT CLUSTER
IPM (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH)
JOINT CONNECTOR JMA (CENTER OF DASH)
JOINT CONNECTOR JMD (RIGHT CENTER
LEFT FRONT WHEEL SENSOR (ON LEFT FRONT STEERING KNUCKLE)
LEFT REAR WHEEL SENSOR (ON LEFT REAR BRAKE BACKING PLATE)
MICOM
NCA WIRE
OF DASH)
OPEN WITH BRAKE PEDAL DEPRESSED
ORG/ WIRE
PCM
PNK WIRE
RED WIRE
RFP-MOTOR C-CAN LOW
RIGHT FRONT WHEEL SENSOR (ON RIGHT FRONT STEERING KNUCKLE)
RIGHT REAR WHEEL SENSOR (ON RIGHT REAR BRAKE BACKING PLATE)
SIGNAL
STOP LAMP FUSE
STOP LAMP SWITCH
STOP LAMP SWITCH SIGNAL +ECU VCC VCC
STOP SIGNAL FUSE
VBATT C-CAN HIGH WHL SPD SNSR OUT
VCC VCC SIGNAL
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, without esc -> STOP LAMP SWITCH SIGNAL +ECU VCC VCC
