Kia Sedona II facelift (2010-2014) power left power tail gate sliding door switch switch close Wiring diagram
This page shows the only wiring diagram for the component.power left power tail gate sliding door switch switch close, which is found in the car Kia Sedona II facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power left power tail gate sliding door switch switch close (1 of 1)
A/C CONTROL MODULE
ADJUST PEDAL SWITCH
AMP
ATM LEVER SWITCH
AUTO A/C
AUTOMATIC A/C
BLK WIRE
CIGARETTE LIGHTER POWER OUTLET
CLUSTER IONIZER
DATA LINK CONNECTOR
DIGITAL CLOCK, TELLTALE
ELECTRO- CHROMIC MIRROR
FRONT BLOWER RELAY
FRONT WIPER DEFOGGER SWITCH
GLOVE BOX LAMP/ SWITCH
IGNITION KEY ILL, DOOR WARNING SWITCH
IMMOBILIZER MODULE
INSTRUMENT CLUSTER
JOINT CONNECTOR JMA (CENTER OF DASH)
JOINT CONNECTOR JMC (CENTER OF DASH)
KEY INTERLOCK SOLENOID
LEFT VANITY LAMP
MANUAL A/C
MAP LAMP
MULTI- FUNCTION SWITCH
NCA WIRE
OVERHEAD CONSOLE
PASSENGER DOOR MODULE
POWER LEFT POWER TAIL GATE SLIDING DOOR SWITCH SWITCH CLOSE
POWER SLIDING/DOOR/POWER TAIL GATE SWITCH
POWER SWITCH
REAR BLOWER RELAY
REAR DEFOGGER
RHEOSTAT
RIGHT LEFT
RIGHT POWER SLIDING DOOR SWITCH
RIGHT VANITY MAP LAMP LAMP
RSE MODULE
SEAT WARMER RELAY
SLIDE OPEN
STEERING ANGLE SENSOR
SUNROOF SWITCH
TILT UP
TIRE PRESSURE MONITORING MODULE
TRIP SUNROOF COMPUTER MODULE
W/ RCD
W/ W/O IMS IMS
W/O IMS
W/O RCD
W/O W/ OVERHEAD OVERHEAD CONSOLE CONSOLE
Go to component -> Ground distribution circuit (2 of 4) -> POWER LEFT POWER TAIL GATE SLIDING DOOR SWITCH SWITCH CLOSE
