Kia Sedona II facelift (2010-2014) instrument cluster circuit Wiring diagram
This page shows the only wiring diagram for the component.instrument cluster circuit, which is found in the car Kia Sedona II facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram instrument cluster circuit (1 of 1)
5 11 BCM-FC 34 42 BCM-FE
70 92 CLG-A
AMB SIG
AMBIENT TEMPERATURE SENSOR 2
BCM-IF
BCM-IM
BEC-IF
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
FAM (FRONT AREA MODULE) (LEFT FRONT OF ENGINE COMPT)
FUEL CONSUMPTION
FUEL SENDER
FUSE
GRN WIRE
GROUND
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ILL
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CIRCUIT
IPM (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH)
MEMORY FUSE
MEMORY POWER
ON/START
PCM
PNK ENG SPEED WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
SHUNT CONNECTOR
TRIP COMPUTER
VSS
WHT WIRE
WHT/BLK WIRE
YEL/BLK WIRE
Go to component -> Trip computer circuit -> INSTRUMENT CLUSTER CIRCUIT
