Kia Sedona II facelift (2010-2014) esc off switch Wiring diagrams
This page contains all the electrical diagrams for the component. esc off switch, in which he is found in the car Kia Sedona II facelift (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
esc off switch wiring diagram (1 of 2)
ABS 1 FUSE
ABS 2 FUSE
ABS IND.
BEC-FE
BEC-FF
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
CLOSE WITH BRAKE PEDAL DEPRESSED
COMPUTER DATA LINES SYSTEM
EBD IND
ESC FUNCTION
ESC MODULE (A/T) (LEFT REAR OF ENGINE COMPT)
ESC OFF SWITCH
FAM (FRONT AREA MODULE) (LEFT FRONT OF ENGINE COMPT)
GRN WIRE
GRN/BLK WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT WHEEL SENSOR (ON LEFT FRONT STEERING KNUCKLE)
LEFT REAR WHEEL SENSOR (ON LEFT REAR BRAKE BACKING PLATE)
NCA WIRE
OPEN WITH BRAKE PEDAL DEPRESSED
ORG/ WIRE
PARKING BRAKE SIGNAL ESC IND
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PNK WIRE
RED WIRE
RED/BLK WIRE
RFP-MOTOR C-CAN LOW
RIGHT REAR WHEEL SENSOR (ON RIGHT REAR BRAKE BACKING PLATE)
SIGNAL
STOP LAMP FUSE
STOP LAMP SWITCH
STOP LAMP SWITCH SIGNAL +ECU VCC VCC
STOP SIGNAL FUSE
VBATT C-CAN HIGH WHL SPD SNSR OUT
VCC VCC SIGNAL
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, with esc (1 of 2) -> ESC OFF SWITCH
esc off switch wiring diagram (2 of 2)
1 2 3 4 5 ANTENNA+ ANTENNA- GROUND POWER K-LINE
4 74 IND DATA LINE
BEC-FE
BEC-IM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
CLG-A
ECU 1 FUSE
ESC OFF SWITCH
FAM (FRONT AREA MODULE) (LEFT FRONT OF ENGINE COMPT)
GRN WIRE
GRN/ORG WIRE
HOT IN ON OR START
HOT W/ ENGINE CONTROL RELAY ENERGIZED
IG 1 FUSE
IGNITION KEY ILL., DOOR
IMMOBILIZER IND
IMMOBILIZER MODULE (LEFT SIDE OF DASH)
INSTRUMENT CLUSTER
IPM (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH)
J/C JMA (CENTER OF DASH)
J/C JMD (RIGHT CENTER OF DASH)
NCA WIRE
ON/START
PCM
RED WIRE
TIRE PRESSURE MONITORING MODULE (BEHIND CENTER OF DASH)
WARNING SWITCH ANTENNA COIL
Go to component -> Immobilizer circuit -> ESC OFF SWITCH
