Kia Sedona II facelift (2010-2014) engine coolant cooling temperature fan sensor relay, sender Wiring diagram
This page shows the only wiring diagram for the component.engine coolant cooling temperature fan sensor relay, sender, which is found in the car Kia Sedona II facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine coolant cooling temperature fan sensor relay, sender (1 of 1)
ABS CONTROL ESC MODULE MODULE
AMBIENT TEMPERATURE LEFT SIDE SENSOR 2 MARKER (TRIP) LAMP
AUDIO
AUTOMATIC MANUAL A/C A/C
BATTERY
BATTERY BODY GROUND GROUND
BCM-FE
BCM-IF (BEHIND LEFT SIDE OF DASH)
BCM-IF IPM (INSTRUMENT PANEL MODULE)
BEC-FE
BLK WIRE
BRAKE FLUID LEVEL SENSOR
BURGLAR ALARM HORN
CIGARETTE LIGHTER POWER OUTLET
CLG-A
COOLING FAN CONTROLLER
DATA LINK CONNECTOR
DRIVER DOOR MODULE
ENGINE COOLANT COOLING TEMPERATURE FAN SENSOR RELAY, SENDER
ESC MODULE
ETC MOTOR, THROTTLE IGNITION POSITION COIL 6 SENSOR SHIELD SHIELD
FRONT FET A/C (FIELD EFFECT CONTROL TRANSISTOR) MODULE
FRONT WIPER DEICER
FRONT WIPER ON RELAY
FRONT YAW WIPER RATE MOTOR SENSOR
HOOD SWITCH
HORN
IGNITION COIL 1,3,5 SHIELD
IGNITION IGNITION COIL 2 COIL 4 SHIELD SHIELD
LEFT FOG LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEAD- LAMP
MEDIA MEDIA JACK RSE MODULE JACK SHIELD
MULTIFUNCTION SWITCH
MULTIPURPOSE CHECK CONNECTOR
NCA WIRE
PCM
RAIN TRIP SENSOR COMPUTER
REAR WASHER MOTOR RELAY
RIGHT FOG LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEAD- LAMP
RIGHT SIDE MARKER LAMP
W/ ESC
W/ W/ W/ ABS ESC ABS
WASHER LEVEL SENSOR
WASHER MOTOR
Go to component -> Ground distribution circuit (1 of 4) -> ENGINE COOLANT COOLING TEMPERATURE FAN SENSOR RELAY, SENDER
