Kia Sedona II facelift (2010-2014) driver sunroof door module module Wiring diagram
This page shows the only wiring diagram for the component.driver sunroof door module module, which is found in the car Kia Sedona II facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver sunroof door module module (1 of 1)
A/C COMP FUSE
A/C COMP RELAY
A/C CONTROL MODULE
ADM FUSIBLE LINK
AMP
AMP FUSE
ASS P/SEAT DRV P/SEAT
ATM FUSE
AUTOMATIC A/C
BATTERY POWER FEED TO BCM
BEC-FE
BEC-FF
BEC-IF
BEC-IM
BLK WIRE
BLU WIRE
DATA LINK CONNECTOR
DDM SUNROOF FUSIBLE LINK FUSE
DRIVER SUNROOF DOOR MODULE MODULE
FROM (FAM) FRONT AREA MODULE, IPM 3 FUSIBLE LINK (DIAGRAM 2 OF 4)
FROM HORN FUSE (DIAGRAM 1 OF 4)
FRONT BLOWER RELAY RELAY BOX (BEHIND RIGHT FRONT OF CENTER CONSOLE)
FRONT WIPER LO/HI RELAY
FRONT WIPER ON RELAY
FRT BLOWER FUSIBLE LINK
FRT WIPER FUSIBLE LINK
FUEL PUMP FUSE
FUEL PUMP RELAY
FUSE FUSE
GRN WIRE
ILLUMI FUSE
IPM 1 FUSIBLE LINK
IPM 2 FUSIBLE LINK
IPM 3 FUSIBLE LINK
K/LOCK FUSE
KEY INTERLOCK RELAY
MANUAL A/C
MAP LAMP
MULTIPURPOSE CHECK CONNECTOR
OBD II FUSE
ORG/ WIRE
OVERHEAD CONSOLE (IF EQUIPPED)
P/N RELAY
P/OUTLET 1 FUSE
PASSENGER ADJUST DOOR PEDAL RELAY MODULE (W/O IMS)
PASSENGER DRIVER POWER POWER SEAT SEAT MODULE MODULE
PEDAL FUSE
REAR BLOWER RELAY
REAR ROOM LAMP SWITCH
RED WIRE
RELAY BOX (BEHIND RIGHT FRONT OF CENTER CONSOLE)
RIGHT MAP LAMP ELECTRO (W/O OVERHEAD CONSOLE)
RR BLOWER FUSIBLE LINK
SEAT WARMER FUSE
SEAT WARMER RELAY
SHUNT ROOM CONNECTOR FUSE
STOP LAMP FUSE
STOP LAMP SWITCH
STOPLAMP FUSE CHECK
TIRE PRESSURE MONITORING MODULE
TO (IPM) INSTRUMENT PANEL MODULE, ROOM FUSE (DIAGRAM 2 OF 4)
TO CIGARETTE LIGHTER (DIAGRAM 4 OF 4)
TO MEMORY FUSE (DIAGRAM 3 OF 4)
TO RAM 1 FUSIBLE LINK (DIAGRAM 3 OF 4)
W/ IMS W/O IMS
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> DRIVER SUNROOF DOOR MODULE MODULE
