Kia Sedona II facelift (2010-2014) audio remote control Wiring diagram
This page shows the only wiring diagram for the component.audio remote control, which is found in the car Kia Sedona II facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram audio remote control (1 of 1)
1 2 3 4 5 6 7 8 SPEED ILL (+) REMOTE ANTENNA BATTERY VOLTAGE
A GND
ACC/ON INPUT ILL (-) GROUND
AM/FM FEEDER CABLE
AUDIO
AUDIO FUSE
AUDIO L+
AUDIO R-
AUDIO REMOTE CONTROL
BEC-IM
BLK RED/ WIRE
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
CLOCK- SPRING
COMPUTER DATA LINES SYSTEM INTERIOR LIGHTS SYSTEM
DASH)
FUSE
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IG 1 FUSE
ILL
IPM (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH)
J/C JMC
J/C JMD
MODE
MULTIFUNCTION SWITCH
MUTE VOL UP VOL DOWN
NCA WIRE
PNK WIRE
PNK/BLK WIRE
REAR REMOTE SURROUND ON/OFF
RED WIRE
RED/BLK WIRE
ROOF ANTENNA CIRCUIT (ROOF)
RSE MODULE (UNDER REAR ROOF CONSOLE)
RSE-IN GND RSE-R-CH-IN RSE-L-CH-IN
STEERING WHEEL)
V GND
VIDEO JACK
VIDEO+
WHT WIRE
WHT/BLK WIRE
XM-FEEDER CABLE
YEL WIRE
YEL/BLK WIRE
Go to component -> Premium radio circuit, without navigation with rear seat entertainment (1 of 2) -> AUDIO REMOTE CONTROL
