Kia Sedona II facelift (2010-2014) 3 bcm-im ig key remind switch input Wiring diagram

3 BCM-IM IG KEY REMIND SWITCH INPUT 34 BCM-IM HEAD LAMP SWITCH INPUT 37 38 5 B-CAN LOW B-CAN HIGH LEFT DR OPEN SW IN 42 BCM-IF SEAT BELT SWITCH INPUT B-CAN B-CAN HIGH B-CAN LOW BCM-IF BCM-IM BEC-IF BEC-IM BLK WIRE BLU WIRE BLU/ORG WIRE COMPUTER DATA LINES SYSTEM DDM FUSE DOOR OPEN IND DRIVER DOOR KEY SWITCH DRIVER DOOR MODULE (IN DRIVER'S DOOR) DRIVER DOOR SWITCH DRIVER SEAT BELT SWITCH FUSE GRN WIRE GRN/ORG WIRE HEAD PARK HOT AT ALL TIMES HOT IN ON OR START IG KEY HOLE ILL IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH IND INSTRUMENT CLUSTER IPM (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH) J/C JMD (RIGHT CENTER OF DASH) KEY CYLINDER LOCK KEY CYLINDER UNLOCK LEFT "C" PILLAR) LIGHT SWITCH LOCK MEMORY FUSE MEMORY POWER MICOM MULTI- FUNCTION SWITCH NCA WIRE OFF ORG/ WIRE RAM (REAR AREA MODULE) (LEFT REAR CORNER OF VEHICLE) RED WIRE RELAY SEAT BELT IND UNLOCK W/S WHT WIRE YEL WIRE
