Kia Sedona II facelift (2010-2014) 25 bcm-im front wiper deicer sw in Wiring diagram
This page shows the only wiring diagram for the component.25 bcm-im front wiper deicer sw in, which is found in the car Kia Sedona II facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 25 bcm-im front wiper deicer sw in (1 of 1)
25 BCM-IM FRONT WIPER DEICER SW IN
30 BCM-IF B-CAN HIGH
B-CAN LOW
BCM-FE
BEC-FE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE RUNNING INPUT
FAM (FRONT AREA MODULE) (LEFT FRONT OF ENGINE COMPT)
FRONT WIPER DEICER
FRONT WIPER DEICER ON/OFF CHECK
FRONT WIPER DEICER RELAY
FRONT WIPER DEICER SWITCH
FRT DEICER FUSE
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
ILL
IND
IPM (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH)
J/C JMC (CENTER OF DASH)
NCA WIRE
PNK IND OUTPUT WIRE
PNK WIRE
RED WIRE
STARTING/ CHARGING SYSTEM
TIMER B- CAN CAN HIGH LOW
WHT WIRE
Go to component -> Front wiper deicer circuit -> 25 BCM-IM FRONT WIPER DEICER SW IN
