Kia Sedona II facelift (2010-2014) 11 12 13 14 15 16 tread ind tpms chk ind Wiring diagram
This page shows the only wiring diagram for the component.11 12 13 14 15 16 tread ind tpms chk ind, which is found in the car Kia Sedona II facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 11 12 13 14 15 16 tread ind tpms chk ind (1 of 1)
1 2 3 4 5 6 7 8 9 BATT VOLT ON/START INPUT
11 12 13 14 15 16 TREAD IND TPMS CHK IND
BEC-IM
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IG 1 FUSE
INSTRUMENT CLUSTER
IPM (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH)
J/C JMA (CENTER OF DASH)
J/C JMD (RIGHT CENTER OF DASH)
K LINE
RED WIRE
TIRE PRESSURE MONITORING MODULE (BEHIND CENTER OF DASH)
TPMS IND
TPMS TREAD IND
VEHICLE SPEED SENS
WHT WIRE
WHT/BLK WIRE
Go to component -> Tire pressure monitoring circuit -> 11 12 13 14 15 16 TREAD IND TPMS CHK IND
