Kia Sedona II (2005-2010) Driver heated seat circuit

1 2 3 4 5 6 7 8 POWER SENSOR POWER (+) (-) SEAT WARMER IN GND SENSOR BEC-IM BLK WIRE BLU WIRE BRN WIRE BRN/ORG WIRE CONTROLLER FUSE GRN WIRE HOT AT ALL TIMES HOT IN ON ILL IPM (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH) LEFT BACK WARMER LEFT CUSHION WARMER LEFT SEAT WARMER SWITCH RED WIRE RED/GRN WIRE RELAY BOX (BEHIND RIGHT FRONT OF CENTER CONSOLE) SEAT WARMER FUSE SEAT WARMER RELAY WHT WIRE WHT/BLK WIRE YEL WIRE
