Car Wiring Diagrams for Cruise control circuit for Kia Sedona II (2005-2010)

ABS CONTROL MODULE (AT LEFT REAR OF ENGINE COMPT) ACCEL POSITION SENSOR (ABOVE ACCELERATOR PEDAL ASSEMBLY) BCM-FC BCM-FE BEC-FC BEC-FE BEC-FE BEC-FE BEC-IM BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE CLOCK- SPRING CRUISE IND CRUISE MAIN CRUISE REMOCON SWITCH (+) (-) CRUISE SET IND ESC MODULE (A/T) (LEFT REAR OF ENGINE COMPT) ETC MOTOR, THROTTLE POSITION SENSOR (REAR OF ENGINE) FRONT AREA MODULE (FAM) (LEFT FRONT FRONT AREA MODULE (FAM) (LEFT FRONT OF ENGINE COMPT) GRN WIRE GRN/ORG WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IG 1 FUSE ILLU INSTRUMENT CLUSTER INSTRUMENT PANEL MODULE (IPM) (BEHIND LEFT SIDE OF DASH) MICOM CAN MULTIFUNCTION SWITCH OF ENGINE COMPT) PCM PNK WIRE REAR AREA MODULE (RAM) (LEFT REAR CORNER OF VEHICLE) RED WIRE RESUME/ ACCEL SET/ COAST SHIFT INTERLOCK SYSTEM STEERING WHEEL) STOP LAMP FAIL CHECK CIRCUIT STOP LAMP FAILURE IND STOP LAMP FUSE STOP LAMP FUSE CHECK STOP SIGNAL FUSE W/ ABS W/ ESC W/ STOP LAMP FAILURE W/O STOP LAMP FAILURE WHT WIRE WHT/BLK WIRE YEL WIRE

A/C CONTROL MODULE (AUTOMATIC A/C) (CENTER OF DASH, BEHIND A/C CONTROL PANEL) AMP (ON FLOOR, UNDER FRONT PASSENGER'S SEAT) BCM-FE BEC-FE BEC-FF FRONT AREA MODULE (FAM) (LEFT FRONT OF ENGINE COMPT) BEC-FC BCM-FC BEC-IF BEC-RR BLK WIRE DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) ENG FUSE GRY WIRE HOT IN ON OR START INSTRUMENT PANEL MODULE (IPM) (BEHIND LEFT SIDE OF DASH) LEFT POWER SLIDING DOOR MODULE (BEHIND LEFT REAR QUARTERPANEL) PNK WIRE POWER TAIL GATE MODULE (LEFT ``D" PILLAR) REAR AREA MODULE (RAM) (LEFT REAR CORNER OF VEHICLE) RED WIRE RIGHT POWER SLIDING DOOR MODULE (BEHIND RIGHT REAR QUARTERPANEL) TRIP COMPUTER VEHICLE SPEED SENSOR (TOP RIGHT SIDE OF TRANSAXLE) WHT WIRE WHT/BLK WIRE
