Kia Sedona II (2005-2010) tread ind chk ind fr fl rr rl Wiring diagram
This page shows the only wiring diagram for the component.tread ind chk ind fr fl rr rl, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tread ind chk ind fr fl rr rl (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 B+ IGN
BEC-IM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GRN WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
IPM (BEHIND LEFT SIDE OF DASH)
JOINT CONNECTOR
K-LINE RF SIG LF SIG RR SIG LR SIG GND
LEFT FRONT TPMS INITIATOR (LEFT FRONT WHEELWELL)
LEFT REAR TPMS INITIATOR (FRONT OF LEFT REAR WHEELWELL)
MICOM
ORG/ WIRE
RED WIRE
RED/ORG WIRE
RIGHT FRONT TPMS INITIATOR (RIGHT FRONT WHEELWELL)
RIGHT REAR TPMS INITIATOR (FRONT OF RIGHT REAR WHEELWELL)
TIRE PRESSURE MONITORING MODULE (BEHIND CENTER OF DASH)
TPMS IND
TREAD IND
TREAD IND CHK IND FR FL RR RL
WHT WIRE
WHT/ORG WIRE
YEL/BLK WIRE
Go to component: -> Tire pressure monitoring circuit -> TREAD IND CHK IND FR FL RR RL
