Kia Sedona II (2005-2010) timer can can high low Wiring diagram

This page shows the only wiring diagram for the component.timer can can high low, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram timer can can high low (1 of 1)

Wiring diagram timer can can high low for Kia Sedona II (2005-2010)

Get access

30 BCM-IF CAN HIGH BCM-FE BEC-FE BLK WIRE BLU WIRE BRN WIRE CAN LOW COMPUTER DATA LINES SYSTEM FAM (FRONT AREA MODULE) (LEFT FRONT OF ENGINE COMPT) FRT DEICER FUSE GRN/BLK WIRE HOT AT ALL TIMES ILL IMP (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH) IND ON/OFF CHECK PNK IND WIRE PNK WIRE RED WIRE TIMER CAN CAN HIGH LOW WHT WIRE WINDSHIELD DEFOG SWITCH INPUT 25 BCM-IM WINDSHIELD DEFOGGER (LEFT REAR OF ENGINE COMPT) WINDSHIELD DEFOGGER RELAY WINDSHIELD DEFOGGER SWITCH

Go to component: -> Heated windshield circuit -> TIMER CAN CAN HIGH LOW
