Kia Sedona II (2005-2010) right turn lamp sw in Wiring diagram
This page shows the only wiring diagram for the component.right turn lamp sw in, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right turn lamp sw in (1 of 1)
BCM-FE
BCM-IF
BCM-IM
BEC-FE
BEC-FF
BEC-IF
BEC-IM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
ENG FUSE
FUSE
GRN WIRE
HAZARD SW INPUT
HEAD
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
INSTRUMENT PANEL MODULE (IPM) (BEHIND LEFT SIDE OF DASH)
IPS
IPS IPS
JOINT CONNECTOR
LEFT
LEFT FRONT TURN LAMP
LEFT SIDE MARKER LAMP
LEFT TURN IND
LEFT TURN LAMP SW IN
LIGHT SWITCH
MEMORY FUSE
MICOM
MULTI- FUNCTION SWITCH
OFF PARK
ORG/ WIRE
PNK (MANUAL A/C) (AUTOMATIC A/C) WIRE
PNK WIRE
RED WIRE
RIGHT
RIGHT FRONT TURN LAMP
RIGHT SIDE MARKER LAMP
RIGHT TURN IND
RIGHT TURN LAMP SW IN
SHUNT CONNECTOR
STOP LAMP FAILURE IND
TAIL LAMP
TAIL LAMP SW INPUT
TAIL LAMP TURN LAMP
TURN LAMP
TURN LAMP SWITCH
YEL WIRE
Go to component: -> Exterior lamps circuit (1 of 2) -> RIGHT TURN LAMP SW IN
