Kia Sedona II (2005-2010) right selector switch wiring diagram
This page shows the only wiring diagram for the component.right selector switch, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right selector switch wiring diagram (1 of 1)
BLK WIRE
DEFOGGER
DEFOGGER SYSTEM
DEFOGGER UP/ DOWN LEFT/ RIGHT
FUSE (BEHIND LEFT SIDE OF DASH) BEC-IF
GRN WIRE
HOT IN ACC OR ON
ILL
INSTRUMENT PANEL MODULE (IPM)
LEFT
LEFT OUTSIDE MIRROR
LEFT POWER OUTSIDE MIRROR MOTOR (ON LEFT FRONT DOOR)
LEFT RIGHT
LEFT SELECTOR SWITCH
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER OUTSIDE MIRROR SWITCH
RED WIRE
RIGHT
RIGHT OUTSIDE MIRROR
RIGHT POWER OUTSIDE MIRROR MOTOR
RIGHT SELECTOR SWITCH
SELECTOR SWITCH
UP DOWN
UP/ DOWN DOWN UP DOWN UP
YEL WIRE
Go to component -> Power mirror circuit -> RIGHT SELECTOR SWITCH
