Kia Sedona II (2005-2010) right rear vcc right front vcc right front sig diagnosis ebd ind Wiring diagram
This page shows the only wiring diagram for the component.right rear vcc right front vcc right front sig diagnosis ebd ind, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear vcc right front vcc right front sig diagnosis ebd ind (1 of 1)
30 BCM-FE
ABS 1 FUSIBLE LINK
ABS 2 FUSIBLE LINK
ABS CONTROL MODULE (AT LEFT REAR OF ENGINE COMPT)
ABS FUSE
ABS IND.
BEC-FE
BEC-FF FRONT AREA MODULE (LEFT FRONT OF ENGINE COMPT)
BEC-IF
BEC-IM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE IND
BRN WIRE
CAN HIGH
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
FRONT AREA MODULE (LEFT FRONT OF ENGINE COMPARTMENT)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IG 1 FUSE
INSTRUMENT CLUSTER
INSTRUMENT PANEL MODULE (BEHIND LEFT SIDE OF DASH)
JOINT
JOINT CONNECTOR
LEFT FRONT WHEEL SPEED SENSOR (ON LEFT FRONT STEERING KNUCKLE)
LEFT REAR WHEEL SPEED SENSOR (ON LEFT REAR BRAKE BACKING PLATE)
MICOM
MULTIPURPOSE CHECK CONNECTOR (LEFT FRONT OF ENGINE COMPARTMENT)
NCA WIRE
ORG/ WIRE
PCM
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR (ON RIGHT FRONT STEERING KNUCKLE)
RIGHT REAR VCC RIGHT FRONT VCC RIGHT FRONT SIG DIAGNOSIS EBD IND
RIGHT REAR WHEEL SPEED SENSOR (ON RIGHT REAR BRAKE BACKING PLATE)
STOP LAMP FUSE
STOP LAMP SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
STOP SIGNAL FUSE
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, without esc -> RIGHT REAR VCC RIGHT FRONT VCC RIGHT FRONT SIG DIAGNOSIS EBD IND
