Kia Sedona II (2005-2010) reclining switch slide switch Wiring diagram

This page shows the only wiring diagram for the component.reclining switch slide switch, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram reclining switch slide switch (1 of 1)

Wiring diagram reclining switch slide switch for Kia Sedona II (2005-2010)

Get access

BEC-IF BLK WIRE BLK/RED WIRE BLU/BLK WIRE BLU/WHT WIRE BRN/ORG WIRE FRONT GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES IMP (INSTRUMENT PANEL PASS P/SEAT FUSE MODULE) (BEHIND LEFT SIDE OF DASH) PASSENGER POWER SEAT MODULE (IN FRONT PASSENGER'S SEAT) PASSENGER POWER SEAT SWITCH PNK WIRE PNK/BLK WIRE REAR REAR FRONT RECLINING SWITCH SLIDE SWITCH RIGHT RECLINING MOTOR (IN FRONT PASSENGER'S SEAT) SLIDE 1 SLIDE 2 TILT 1 TILT 2 WHT WIRE YEL WIRE

Go to component: -> Passenger seat circuit -> RECLINING SWITCH SLIDE SWITCH
