Kia Sedona II (2005-2010) off down Wiring diagram

This page shows the only wiring diagram for the component.off down, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram off down (1 of 1)

Wiring diagram off down for Kia Sedona II (2005-2010)

Get access

BCM-IM BEC-IM BLK WIRE BLU WIRE BRN WIRE GRN WIRE HOT AT ALL TIMES ILL IPM (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH) JOINT CONNECTOR OFF DOWN ON/OFF SIGNAL OUTPUT PEDAL ADJUST MOTOR (UNDER LEFT SIDE OF DASH) PEDAL ADJUST RELAY (BEHIND CENTER OF DASH) PEDAL ADJUST SWITCH PEDAL FUSE RED WIRE WHT/BLK WIRE YEL/ORG WIRE

Go to component: -> Adjustable pedal circuit -> OFF DOWN
