Kia Sedona II (2005-2010) left outside mirror Wiring diagram

This page shows the only wiring diagram for the component.left outside mirror, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left outside mirror (1 of 1)

Wiring diagram left outside mirror for Kia Sedona II (2005-2010)

Get access

BLK WIRE DEFOGGER DEFOGGER SYSTEM DEFOGGER UP/ DOWN LEFT/ RIGHT FUSE (BEHIND LEFT SIDE OF DASH) BEC-IF GRN WIRE HOT IN ACC OR ON ILL INSTRUMENT PANEL MODULE (IPM) LEFT LEFT OUTSIDE MIRROR LEFT POWER OUTSIDE MIRROR MOTOR (ON LEFT FRONT DOOR) LEFT RIGHT LEFT SELECTOR SWITCH NCA WIRE ORG/ WIRE PNK WIRE POWER OUTSIDE MIRROR SWITCH RED WIRE RIGHT RIGHT OUTSIDE MIRROR RIGHT POWER OUTSIDE MIRROR MOTOR RIGHT SELECTOR SWITCH SELECTOR SWITCH UP DOWN UP/ DOWN DOWN UP DOWN UP YEL WIRE

Go to component: -> Power mirror circuit -> LEFT OUTSIDE MIRROR
