Kia Sedona II (2005-2010) left cushion warmer Wiring diagram

This page shows the only wiring diagram for the component.left cushion warmer, which is found in the car Kia Sedona II (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left cushion warmer (1 of 1)

Wiring diagram left cushion warmer for Kia Sedona II (2005-2010)

Get access

1 2 3 4 5 6 7 8 POWER SENSOR POWER (+) (-) SEAT WARMER IN GND SENSOR BEC-IM BLK WIRE BLU WIRE BRN WIRE BRN/ORG WIRE CONTROLLER FUSE GRN WIRE HOT AT ALL TIMES HOT IN ON ILL IPM (INSTRUMENT PANEL MODULE) (BEHIND LEFT SIDE OF DASH) LEFT BACK WARMER LEFT CUSHION WARMER LEFT SEAT WARMER SWITCH RED WIRE RED/GRN WIRE RELAY BOX (BEHIND RIGHT FRONT OF CENTER CONSOLE) SEAT WARMER FUSE SEAT WARMER RELAY WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component: -> Driver heated seat circuit -> LEFT CUSHION WARMER
